Leak Test Application from TQC

Water Valve Leak Test System using "Differential Pressure with Water"

Water valves with diameters of 20-100mm can be leak tested both internally and externally using the 'differential pressure with water' technique.

The features of the machine include easily removable tools for the  variable diameters of valves and torque control for closing the valve, and rotation control at opening and closing of the valve. The control panel is accessible, with a keyboard for the setting of parameters, such as programmes, times, alarm points and pressures. The display indicates the test process, pressures and a test result in pascals. A separate pump stand allows access for maintenance.The measurement pneumatic equipment is contained within a separate enclosure.

There is a pressure tank and return water tank with requisite filters and valves included, and a sugevac vaccum pump for vaccum pumping of the valve before filling with water, which provides a high filling rate and eliminates the fill time before pressure stabilisation. the maximum external test pressure is 25 bar. A drip tray is placed under the fixture to collect waste water and at the lowest point, there is a pump for the evacuation of waste water.

Upon activation of the start button, the valve is automatically loaded and the protective guard descends, and automatically locks. The guard may be opened after the test pressure has been reached to allow for visual leak location. The machine is equipped with clear protective guards and safety switches on three sides to allow for valve maintenance and filter exchange.


Water Valve Leak Test System Part Load & Unload Shuttle

Technical Data :

  • Test piece: Water valve, diameter 20-100mm
  • External Pressure: 40 bar
  • Internal pressure: 25bar
  • Leak Rate:2 drops water per sec
  • Cycle Time: Approx 70 sec (without handling)
  • Connections: Power supply 240/400 V 50Hz, Air approx 6 bar, water and drain BSP/NPT threads

If you have a current project that you are already looking at, or you are considering improvements to your production in the near future, call us and we will be happy to offer our professional advice & visit you at your site.
